Vento 62
Pressure Control, Time Cycle continues flow Ventilator.
Support patients that required ventilation from (20 to
2000 ml Vt)
Exceptional ventilation modes and tools help clinicians to
provide safer ventilation and successfully wean the patient
from the ventilator.
Intuitive layout and easy to use, focus to reduce the
learning curve and risks of errors
Equipped with EtCo2 and SPO2 (optional), provides
additional information about the breathing progress
Manufactured in Germany, under the strictest quality
standards, delivering precise and reliable ventilator that
you can trust
Supports patient weight between 5 – 150 Kg
Built-in battery operating up to 2 hours
Air Compressor, designed to work 24 x 7. Low-noise design to
meet requirements of ward environment.
Equipped with EtCO2 and SPO2 (optional), provides additional information
about the breathing progress
▪ 1. Automatic draining and filtrating.
▪ 2. Automatic temperature and pressure protection.
▪ 3. Automatic malfunction alarms function.
▪ 4. Pressure, temperature, continuous operating time and error codes displaying function
Intuitive layout and easy to use Ventilator
Equipped with a non-reflective high resolution 15“ TFT Touch
Screen monitor and rotatory knob to easy navigation
Eight different ventilation modes to fulfill all requirement of
intensive patient care units (VCV, PCV, SIMV-PC, SIMV-VC,
PRVC, DualPAP, Spontaneous breathing modes and NIV)
Outstanding tools that help the clinicians to assess better
the patient conditions before waring
Functions for most common procedures are accessed from the
front panel
Display up to 4 waveforms and 2 loops simultaneously,
allowing the clinicians to have a better assessment of the
patient conditions with a simple look of the screen.
Patient respiratory phase are color coded for easy identification
and interpretation for the clinicians.
User can select up to 4 different Loops: P-V, F-V and P-F
(V-CO2 optional).
Trends of different parameters for up to 24hrs, which allow
clinicians to assess the condition after any treatment or
change of shift
System Log
System Settings
Patient Measurements
Alarm Settings
Static compliance represents pulmonary compliance during
periods without gas flow, such as during an inspiratory pause.
Continuous, reliable measurement of static compliance of the
lung and thorax is of the utmost importance in state-of-the-art
mechanical ventilation.
ETT Compensation. Patients will be benefits from this new
option to compensates for the tube-related additional Work of
Breathing for the non-linearly flow-dependent pressure drop
across an endotracheal or tracheostomy tube (ETT) during
inspiration and expiration.
Vento62 is capable to compensate leakages up to 60% of
VT, allowing the clinicians to work in high leakage
environment and improve Patient-Ventilator Synchrony
▪ EtCO2 Module (Masimo CO2 Module). End-tidal CO2
monitoring has also been useful for breathing retraining, as
it provides additional information about the progress of a
person’s breathing normalization.
▪ SPO2 Module (optional). Allow the clinicians to monitor
the patient SPO2, without the need of an external monitor.
▪ The Vento62 comes standard with the Integrated
Synchronize Pneumatic Nebulizer
▪ Key components from world leading manufacturers to
ensure durability and precision. We design our products for
minimum downtime and long-lasting performance, so they
generate a significant return on customer investment over
a sustained period.
▪ The internal Power Supply is design to allow Vento62 to
fulfill more adverse voltage conditions.
▪ Each Vento 62 is Certified before leaving the factory and
must pass a rigorous quality test. In this way we guarantee
that the equipment reaches our customers in compliance
with the highest quality standards.
▪ Expiration Valve incorpore the pressure differentiator
sensor easy to disassemble for cleaning, disinfection and
sterilization (Autoclave at 134 C˚ for 10 min)
